W1209 1 Kanalo Relė Modulis su Temperatūros Jutikliu ( termostatas )

W1209 1 Kanalo Relė Modulis su Temperatūros Jutikliu ( termostatas )

Name: W1209 1 Kanalo Relė Modulis su Temperatūros Jutikliu ( termostatas )
SKU: AN0214-16 / 0236 / PPK-W1209
Price: 6 EUR
Availability: InStock

Aukšto tikslumo temperatūros valdiklis/ jungiklis (termostatas) mini temperatūros valdymo plokštė STC3018 24V

Read moreShow less

Kaina €6.00 (tax incl.)

Turime sandelyje

QR code

Reference:

AN0214-16 / 0236 / PPK-W1209

Description

Supply voltage: DC 12V
Static current: ≤35MA, attract current ≤65MA
Output voltage: DC 12V
Output power: 20A relay
Measurement input: NTC (10K 0.5%) Waterproof Sensor
Environmental requirements: -10 ~ 60℃, Humidity 20% ~ 85%
Dimensions: 48 x 40mm
Cable length: About 52 cm
Temperature control mode: ON / OFF
Temperature range: -50 ~ +110°C
Control accuracy: 0.1°C
Hysteresis accuracy: 0.1°C
Refresh rate: 0.5S
High temperature protection: 0 ~ 110°C
Resolution : When temperature is 0.1°C, the resolution is -9.9~99.9, other temperature segment is 1°C
